Document Title Document No. Revision
Date Section
Supplement S3 to the AMM CTLS-LSA –
CTLS-LSA with ROTAX 912iS
AF 0480 0011 00 05-Aug-12 76-00-3
Approval Ref.: Approved on the Basis of Manufacturer Self Declaration
Fig. Item
Part Name Torque Reference
1 Main Plate KF76000151
2 Covering Plate KF76000001
3 Grip KF76000132
4 Grip KF76000131
5 Bolt DIN 7991 M6x35 A2-70
C9996219
6 Grip
KF32400010
7 Grip
KF32400012
8 Bolt DIN 7991 M6x30 A4
C9996218A
9 Countersunk rivet nut, steel, M5 C9996834
10 Holder DC76000101
11 Bolt DIN 912 M6x30-8.8 C9996059
12 Bolt DIN 912 M4x20-8.8 C9996026
13 Support DC76000156
14 Angle KC76000152
15 Bolt DIN 912 M4x16-8.8 C9996025
16 Angle KC76000154
17 Support KC76000105
18 Bolt DIN 933 M4x18-8.8 C9996282E
19 Steel rope 7x7 1 mm С9997065B
20 Bolt DIN 912 M6x70-8.8 C9996065
21 Throttle Lever DC76000130
22 Screw ISO 7380 M5x12 A2-70 С9996161
23 Plate KC76000137
24 Bolt DIN 931 M6x35-8.8 C9996259B
25 Brakes Lever KF32400011
26 Machine screw DIN 965 M2x10-4.8 C9990018D
27 S2 Rocker Switch C9990018D
28 Self- locking nut DIN 985-M6, regular C9996334
29 Yoke Roller KF76000136
76-00-2
30 Roller KF76000134
To Next Page
