Document Title Document No. Revision
Date Section
Supplement S3 to the AMM CTLS-LSA –
CTLS-LSA with ROTAX 912iS
AF 0480 0011 00 05-Aug-12 78-00-2
Approval Ref.: Approved on the Basis of Manufacturer Self Declaration
Fig. Item
Part Name Torque Reference
1 Forward exhaust pipe, right KF78000010
2 Rear exhaust pipe, right KF78000020
3 Forward exhaust pipe, left KF78000030
4 Rear exhaust pipe, left KF78000040
5 Muffler KF78000050
6 Spring Spring
78-00-1
7 Nut 12 Nm C9996035
78-00.3 Maintenance Practices
78-00.3.1 Exhaust Muffler Removal
78-00.3.1.1 Type of Maintenance
Line
78-00.3.1.2 Minimum Level of Certification
Repairman, Light Sport Aircraft-Maintenance (RLSA-M) or higher
78-00.3.1.3 Procedure
A. Recommended Special Tools and Parts
Item Quantity Unit
None
B. Exhaust Muffler and Pipes Removal
Step Action Reference
1 Cut the safety wire, disconnect Springs (6).
2
Disconnect the cabin heat tube from the heating shroud flange as per
instructions in the basic AMM.
3 Remove the muffler.
4 Inspect muffler and heating shroud for cracks, corrosion and leakages.
5 Mount and secure Muffler in reverse order.
78-00.3.2 Exhaust Muffler and Pipes Inspection
78-00.3.2.1 Type of Maintenance
Line
78-00.3.2.2 Minimum Level of Certification
Repairman, Light Sport Aircraft-Maintenance (RLSA-M) or higher
78-00.3.2.3 Procedure
A. Recommended Special Tools and Parts
Item Quantity Unit
None
