FLIGHT DESIGN CTSW2006 - Type of Maintenance; Minimum Level of Certification Required; General; Used Drawings

Aircraft Type: CTSW 2006
LSA; LTF (BFU)
FLIGHT DESIGN
Trim Tab Spring Modification
Page: 3
Rev. No.:
Original Issue Date: 13.10.2006
Revision Date:
2 Type of Maintenance
Heavy
3 Minimum Level of Certification Required
Repairman, Light Sport Aircraft-Maintenance (RLSA-M). Task Specific: can be
completed only by a responsible individual, which has received Flight Design Airplane
Operation Training.
4 General
Set the plane on parking brake and ensure good access to the tail of the aircraft.
Ensure only new self-locking nut DIN 985 are used.
Please, read all document before start working.
Pay attention all using here spring are under big forces – BE CAREFULL!
5 Used drawings
KA 6060000-01 ASSY o.i.
KA 6060040 ASSY o.i.
6 New parts
Telescopic Guide (KA 6060040 ASSY o.i.)
Spring with 37 turns 260 mm length (like KA 6060007)
