Revision D – August 20th, 2021 Page 1
HL-860F LED Perimeter Light with LED Flood Light
User Instructions
Your Flight Light HL-860FL light fixture has been designed to provide years of service,
please follow the recommendations outlined in this guide.
Contents
A. Safety Measures .............................................................................................. 2
B. Installation ....................................................................................................... 3
1. Base Can Installation..................................................................................... 4
For Existing Pavements: ........................................................................ 5
For new installations: ............................................................................ 8
2. Soil- Stake Installation ................................................................................ 10
C. Wiring ............................................................................................................ 11
1. 90-135VAC .................................................................................................. 12
2. 208-277VAC ................................................................................................ 13
3. 10-30 VDC ................................................................................................... 14
4. 10-30 VDC + Dimming……………………………………………………………………………..………………..15
D. Limited Warranty ........................................................................................... 16
