B. Installation
Each light is packed in its own box 18” x 12” x 12”. Carefully remove the light from its box
and inspect for damages. If any damages are found, file a claim with the carrier.
1. The perimeter light and the flood light are usually wired together in parallel inside the
light fixture so they will both turn ON when power is applied. If you have ordered wiring to
be separate between the two light sources there will be two sets of AC wiring (see step 2
below).
2. There are three wires at the bottom of the fixture for you to connect inside the base can.
Consult your local electrical codes or inspector for the proper wire to use (which should
take local temperature effects into account), AWG14 is adequate for most locations
according to NEC 2014.
Black (AC Line)
White (AC Neutral)
Green (Ground)
The following picture shows the HL-860 LED and Flood Light:
