Choose a stable, solid and supportive wall/wood surface like stone, wood
etc and make sure the lamp is used and faced towards the direction of the
sun (most south location). Suggested mounting height is 2 ~ 3 meters max.
Install the FlinQ Orion lamp
Drill 1 or 2 holes and keep the
distance between the two holes
and horizontal aligned. Use the
mounting plate for reference.
Add the supplied expansion plugs
into each of the drilled holes.
Drill the holes
Place mounting plate
Place plugs
Place lamp
1
3
2
4
Now add the wall mounting plate
with the screws into the wall.
Now, t the product by placing
and sliding it sideways and
downwards with the openings
from the lamp.
FlinQ Smart Outdoor Orion
