3 EN-US English
3.7.3 View from the rear
See Figure 2.3 View from the rear, page 3.
1. Viewfinder.
2. Adjustment knob for the viewfinder’s diopter correction.
3. Cover for the connector compartment.
4. Cover for the battery compartment.
5. Release button for the battery compartment cover.
6. USB-A connector for external USB devices.
7. Power LED indicator.
8.
button (On/off).
The
button has the following functions:
• When the camera is off, push and release to turn on the camera.
• When the camera is on, push and hold for more than 0.2 second to turn
off the camera.
9. Joystick.
The joystick has the following functions:
• To navigate in menus and dialog boxes, move the joystick up/down/left/
right.
• To change values, move the joystick up/down/left/right.
• To select or confirm choices, push the joystick.
10.
button (Menu/Back).
#T810142; r. AB/55671/55671; mul 10
