FLIR K1 User Manual

Programming Menu
6
2. MSX® Alignment: While at the Image Mode menu you can adjust the
MSX® alignment so that the thermal image and the visible image are
superimposed accurately. While viewing the THERMAL PLUS VISIBLE
IMAGE screen in the menu, press MENU to see the MSX® adjustment
screen (shown below) and then use the arrow buttons to adjust the
alignment.
#NAS100007; r. AA/59809/59809; en-US
11

FLIR K1 Specifications

General

Resolution	160 x 120 pixels
Thermal Sensitivity	<70 mK
Drop Test	2 m (6.6 ft)
Image Frequency	9 Hz
Battery Type	Rechargeable Li-ion
Field of View	57° x 44°
Temperature Range	-4 °F to 752 °F (-20 °C to 400 °C)
Battery Life	5 hours
Focus	Fixed
Display	2.4-inch LCD
Image Modes	Thermal
