FLIR Raymarine E22158 - Seatalk Instrument Connection; RS125 GPS Connection

4.8SeaTalkinstrumentconnection
D118 08-2
SeaTalk
ng
SeaTalk
ng
5
3
1
2
4
1.SeaTalkinstruments(poweredfromthe
SeaTalk
ng
bus.)
2.SeaTalk-SeaTalk
ng
adaptorcable(A22164)
(connectiontoseparatedSeaTalkspur.)
3.SeaTalkcable
4.Transducers(connecteddirectlytoinstrument
displays)
5.SeaTalk-SeaTalk
ng
converter(poweredfromthe
SeaTalk
ng
bus.)
4.9RS125GPSconnection
Important:TheGPSconnectsdirectlytothe
SeaTalkconnectionontheconverter.The
connectioncannotbesharedwithotherdevices.
D118 09-3
1
2
SeaTalk
ng
SeaTalk
ng
3
1.RS125(GPS)(poweredfromtheSeaTalk
ng
bus.)
2.RS125convertercable(R32120)
3.SeaTalk-SeaTalk
ng
converter(poweredfromthe
SeaTalk
ng
bus.)
24
SeaTalk–SeaT alkngconverter
