12
USER MANUAL - Rev 1
FLIR
SCOUT
®
III
SECTION 6. SPECIFICATIONS
SCOUT III 240 SCOUT III 320 SCOUT III 640
SENSOR SPECIFICATIONS
Detector Type 240 × 180 VOx
Microbolometer
336 × 256 VOx
Microbolometer
640 × 512 VOx
Microbolometer
Video Refresh Rate 30Hz NTSC 60Hz NTSC 30Hz NTSC
Field of View (H x V) 24° × 18° 17° × 13° 18° × 14°
Focal Length 13 mm Fixed Focus 19mm Fixed Focus 35mm Fixed Focus
Start up < 1.5 seconds
Image Processing FLIR Proprietary Digital Detail Enhancement™
USER INTERFACE
Zoom Button Freeze Frame 2X Zoom 2X, 4X Zoom
Video Detection Palettes User Selectable: Black Hot, White Hot, InstAlert™ and Graded Fire
Brightness Multiple Brightness Levels
Task Light LED (operational when imager power off )
SYSTEM SPECIFICATIONS
Display 640 X 480
Video Output N/A NTSC composite video NTSC composite video
POWER
Battery Type Internal Li-Ion Cell
Battery Life (Operating) >5 hours, Auto-off after 5 minutes of non-use
Battery Power 3.7 V 2400mAh
ENVIRONMENTAL
Rating IP-67, Submersible
Operating Temp. -4°F to 122°F (-20°C to 50°C)
Storage Temp. -40°F to 140°F (-40°C to 60°C)
PHYSICAL
Weight (incl. lens) 12 oz (340 g)
Size (L × W × H) 6.70” x 2.31”x 2.44”
Color (housing) Flat Dark Earth
Country Of Origin USA
RANGE PERFORMANCE
Detect Man (1.8 m × 0.5 m) 380yd (350m) 600yd (550m) 1200yd (1140m)
PACKAGES INCLUDE
Handheld Thermal Monocular, USB Power Adapter/Charger, Wrist strap, Custom Video out cable (320 & 640 version),
USB Cable, Quick Start Guide, Molle bag
