FLIR T10 Series Quick Start

………………………………………………………………………………………………………………………………………………
Detect 1 in. target @ 177ft.
IFOV =.47 mRad (Theoretical with 1024x768 Detector and standard 28˚x21˚ lens)
© 2016 The Snell Group / 322 N. Main St. / Suite 8 / Barre, VT 05641 / 800.636.9820 / www.thesnellgroup.com
T1K
V 2016.7
QuickStart FLIR T1K
10. RECALL IMAGE: Press the Image archive button
• Move the joystick up/down and left/right to select the image
• Push the joystick to display full screen
11. PALETTE: Press the joystick to pull up the menu.
• Select Color.
• Use joystick to select the palette that you want.
12. RANGE: Press the joystick to pull up the menu. Select Settings, then select Temperature Range, then select the
desired range. This function can also be assigned to one of the programmable buttons.
13. EMISSIVITY: Press the joystick to pull up the menu. Select Measurement Parameters, then select Emissivity and
change the value to the desired setting.
14. BACKGROUND (RTC): Press the joystick to pull up the menu. Select Measurement Parameters, then select
Reected Temperature and change the value to the desired setting.

FLIR T10 Series Specifications

General

Brand	FLIR
Model	T10 Series
Category	Thermal cameras
Language	English
