FLIR T1020 Quick Start

………………………………………………………………………………………………………………………………………………
Detect 1 in. target @ 177ft.
IFOV =.47 mRad (Theoretical with 1024x768 Detector and standard 28˚x21˚ lens)
© 2016 The Snell Group / 322 N. Main St. / Suite 8 / Barre, VT 05641 / 800.636.9820 / www.thesnellgroup.com
T1K
V 2016.7
QuickStart FLIR T1K
10. RECALL IMAGE: Press the Image archive button
• Move the joystick up/down and left/right to select the image
• Push the joystick to display full screen
11. PALETTE: Press the joystick to pull up the menu.
• Select Color.
• Use joystick to select the palette that you want.
12. RANGE: Press the joystick to pull up the menu. Select Settings, then select Temperature Range, then select the
desired range. This function can also be assigned to one of the programmable buttons.
13. EMISSIVITY: Press the joystick to pull up the menu. Select Measurement Parameters, then select Emissivity and
change the value to the desired setting.
14. BACKGROUND (RTC): Press the joystick to pull up the menu. Select Measurement Parameters, then select
Reected Temperature and change the value to the desired setting.

FLIR T1020 Specifications

General

Resolution	1024 × 768 pixels
Detector Type	Uncooled microbolometer
Digital Camera	5 MP
Laser Pointer	Yes
Wi-Fi	Yes
Image Frequency	30 Hz
Detector Pitch	17 µm
Digital Zoom	1-8x continuous
Video Recording	Yes
Storage Media	SD card
Spectral Range	7.5 – 14 µm
Temperature Range	-40 °C to +2000 °C (-40 °F to +3632 °F)
Field of View	28° x 21°
Display	4.3 in LCD touchscreen, 800 × 480 pixels
Focus	Motorized and manual
Image Modes	Thermal, visual, MSX
Operating Temperature	-15 °C to +50 °C
Storage Temperature	-40 °C to +70 °C (-40 °F to +158 °F)
Connectivity	USB 2.0, HDMI
Image Storage	JPEG
Image Formats	JPEG
Thermal Sensitivity	<20 mK at 30°C
