FLIR T420 Getting Started Guide

○ Manual min: Using this mode, the bottom temperature level in the scale
can be changed by pushing the joystick up/down, while the top
temperature level remains fixed.
○ Manual max: Using this mode, the top temperature level in the scale can
be changed by pushing the joystick up/down, while the bottom tempera-
ture level remains fixed.
2. Push and hold the button until you hear a clicking sound to autoadjust the
image.
A9 Archive button: Push to open/close the image gallery.
A10 On/Off button: Push to turn on/turn off the camera. Allow 45 seconds for the
start-up sequence.
A11 Hand strap.
© 2012, FLIR Systems, Inc. All rights reserved worldwide.
9
Publ. no. T559755, rev. 000
www.netzerotools.com
www.netzerotools.com

FLIR T420 Specifications

General

Resolution	320 x 240 pixels
Field of View	25° x 19°
Spatial Resolution (IFOV)	1.36 mrad
Image Frequency	60 Hz
Laser Pointer	Yes
Operating Temperature Range	-15°C to +50°C
Storage Temperature Range	-40°C to +70°C
Image Storage	SD Card
Temperature Range	-20°C to +650°C
Focus	Manual
Display	3.5 in. LCD
Battery Life	Approx. 4 hours
Accuracy	±2°C or ±2%
Digital Camera	3.1 MP
Video Recording	Yes
File Format	JPEG
Spectral Range	7.5 - 13 µm
Minimum Focus Distance	0.4 m
Weight	0.88 kg
Interface	USB, Wi-Fi
Image Modes	Thermal, MSX
Thermal Sensitivity	< 0.045°C @ +30°C (+86°F) / 45 mK
