FLIR TG267 Quick Start

DISPLAY DESCRIPTION
See Figure 2, Display Description, in the Illustrations section.
1. Menu area
2. Date and time
3. Battery status percentage
4. Battery status indicator
5. Bluetooth® active (TG267, TG297)
6. USB connection active
7. Camera image area
8. Center spot cross-hairs
9. Laser Pointer active
10. Center spot temperature measurement
11. Thermocouple measurement (TG267)
PROGRAMMING MENU
1. Short press the MENU button to access the menus.
2. Use the up/down arrow buttons to navigate.
3. Use the MENU button to make selections.
4. Use the RETURN button to back up.
5. Pull the trigger to exit the menu system.
6. See menu item list below:
• Main menu: Light (Flashlight), Gallery (saved images), Image
Adjustments, Settings.
• Image Adjustments menu: Image Modes (MSX® or visible cam-
era), Colors (display palettes).
• Settings menu: Measurement, Device, General:
◦ Measurement settings: Center Spot, Emissivity,
Thermocouple.
◦ Device settings: Bluetooth® (TG267, TG297 only), Laser,
Screen brightness, APO.
◦ General settings: Temperature units, Time/Date, Language
selection, System Info (serial number, revision date, etc.),
General System Info (regulatory safety compliance informa-
tion), Factory default reset.
TYPE-K THERMOCOUPLE (TG267)
Connect thermocouple to jack in top compartment. Touch the probe
to a test surface or hold it in air. Read the temperature on the dis-
play (next to TC icon). If necessary, enable the thermocouple mode
in the Settings sub-menu (under Measurements). Do not exceed
the temperature range printed on the thermocouple label. See Fig-
ure 5, Type-K Thermocouple, in the Illustrations section.
#NAS100021; r. AD/64725/64725; mul
3

FLIR TG267 Specifications

General

Temperature Range	-25°C to 380°C (-13°F to 716°F)
Field of View	57° × 44°
Battery Life	Up to 5 hours
Thermal Sensitivity/NETD	< 70 mK
Image Frequency	9 Hz
Focus	Focus free
MSX (Multi-Spectral Dynamic Imaging)	Yes
On-Screen Emissivity Correction	Yes
Image File Format	JPEG
Laser Pointer	Yes
Drop Test	2 m (6.5 ft)
Weight	0.394 kg (0.87 lb)
Dimensions	210 × 64 × 81 mm (8.3 × 2.5 × 3.2 in)
Operating Temperature Range	-10°C to 45°C (14°F to 113°F)
Storage Temperature Range	-40°C to 70°C (-40°F to 158°F)
IP Rating	IP54
IR Resolution	160 × 120 pixels
Battery Type	Rechargeable Li-ion battery
Emissivity	Adjustable from 0.1 to 1.0
Image Modes	Thermal, MSX
Storage Media	Internal memory
Spectral Range	8–14 µm
