FLIR TG267 Quick Start

6. ﺎﺗﺼﺎﻟ USB ﻧﺸﻂ
7. ﻣﻨﻄﻘﺔﺻﻮﺮﺎﻟﻜﺎﻣﲑﺎ
8. ﺎﻟﺸﻌﲑﺎﺗﺎﳌﺘﺼﺎﻟﺒﺔﻟﻠﻨﻘﻄﺔﺎﳌﺮﻛﺰﻳﺔ
9. ﻣﺆﴍﺎﻟﻠﻴﺰﺮﻧﺸﻂ
10. ﻗﻴﺎﺳﺪﺮﺟﺔﺣﺮﺎﺮﺔﺎﻟﻨﻘﻄﺔﺎﳌﺮﻛﺰﻳﺔ
11. ﻗﻴﺎﺳﺎﳌﺰﺪﻮﺟﺔﺎﻟﺤﺮﺎﺮﻳﺔ (TG267)
ﻗﺎﺋﻤﺔﺎﻟﱪﻣﺠﺔ
1. ﺎﺿﻐﻂﻟﻔﱰﺔﻮﺟﻴﺰﺔﻋﲆﺰﺮ MENU ( ﺎﻟﻘﺎﺋﻤﺔ(ﻟﻠﻮﺻﻮﻟﺈﱃﺎﻟﻘﻮﺎﺋﻢ .
2. ﺎﺳﺘﺨﺪﻣﺰﺮﻳﺳﻬﻢﻷﻋﲆ/ﻷﺳﻔﻞﻟﻠﺘﻨﻘﻞ .
3. ﺎﺳﺘﺨﺪﻣﺰﺮ MENU ( ﺎﻟﻘﺎﺋﻤﺔ(ﻟﺘﺤﺪﻳﺪﺎﻟﺨﻴﺎﺮﺎﺗ .
4. ﺎﺳﺘﺨﺪﻣﺰﺮ RETURN ( ﺮﺟﻮﻋ(ﻟﻠﺮﺟﻮﻋﺈﱃﺎﻟﺨﻠﻒ .
5. ﺎﺳﺤﺐﺎﳌﺸﻐّﻞﻟﻠﺨﺮﻮﺟﻣﻦﻧﻈﺎﻣﺎﻟﻘﺎﺋﻤﺔ .
6. ﺎﻃﻠﻊﻋﲆﻻﺋﺤﺔﻋﻨﺎﴏﺎﻟﻘﺎﺋﻤﺔﺄﺪﻧﺎﻩ :
• ﺎﻟﻘﺎﺋﻤﺔﺎﻟﺮﺋﻴﺴﻴﺔ : Light ( ﻣﺼﺒﺎﺣ()ﻛﺸ
ّ
ﺎﻓ(،ﻮ Gallery ( ﻣﻌﺮﺿﺎﻟﺼﻮﺮ()ﺎﻟﺼﻮﺮ
ﺎﳌﺤﻔﻮﻇﺔ(،ﻮ Image Adjustments ( ﺗﻌﺪﻳﻼﺗﺎﻟﺼﻮﺮ(،ﻮ Settings ( ﺎﻹﻋﺪﺎﺪﺎﺗ ).
• ﻗﺎﺋﻤﺔ Image Adjustments ( ﺗﻌﺪﻳﻼﺗﺎﻟﺼﻮﺮ(:ﺄﻮﺿﺎﻋﺎﻟﺼﻮﺮ (MSX® ﺄﻮﺎﻟﻜﺎﻣﲑﺎ
ﺎﳌﺮﺋﻴﺔ(ﻮ Colors ( ﺎﻷﻟﻮﺎﻧ()ﻟﻮﺣﺎﺗﺎﻟﻌﺮﺿ ).
• ﻗﺎﺋﻤﺔ Settings ( ﺎﻹﻋﺪﺎﺪﺎﺗ ): Measurement ( ﺎﻟﻘﻴﺎﺳ )، Device ( ﺎﻟﺠﻬﺎﺰ ) Gener-
al ( ﺎﻹﻋﺪﺎﺪﺎﺗﺎﻟﻌﺎﻣﺔ ):
◦ ﺈﻋﺪﺎﺪﺎﺗ Measurement ( ﺎﻟﻘﻴﺎﺳ ): Center Spot ( ﺎﻟﻨﻘﻄﺔﺎﳌﺮﻛﺰﻳﺔ ) Emissiv-
ity ( ﺎﻟﻨﴩ ) Thermocouple ( ﺎﳌﺰﺪﻮﺟﺔﺎﻟﺤﺮﺎﺮﻳﺔ ).
◦ ﺈﻋﺪﺎﺪﺎﺗ Device ( ﺎﻟﺠﻬﺎﺰ ): Bluetooth® ( ﺎﻟﻄﺮﺎﺰﺎﻧ TG267ﻮTG297 ﻓﻘﻂ(،
ﺎﻟﻠﻴﺰﺮ،ﺳﻄﻮﻋﺎﻟﺸﺎﺷﺔ،ﺈﻳﻘﺎﻓﺎﻟﺘﺸﻐﻴﻞﺎﻟﺘﻠﻘﺎﺋﻲ .
◦ ﺎﻹﻋﺪﺎﺪﺎﺗﺎﻟﻌﺎﻣﺔ:ﻮﺣﺪﺎﺗﺪﺮﺟﺎﺗﺎﻟﺤﺮﺎﺮﺔ،ﺎﻟﺘﺎﺮﻳﺦ/ﺎﻟﻮﻗﺖ،ﺎﻟﻠﻐﺔﺎﳌﺤﻠﻴﺔ،ﻣﻌﻠﻮﻣﺎﺗﺎﻟﻨﻈﺎﻣ
)ﺎﻟﺮﻗﻢﺎﻟﺘﺴﻠﺴﲇ،ﺗﺎﺮﻳﺦﺎﳌﺮﺎﺟﻌﺔﻮﺈﻟﺦ.(،ﻣﻌﻠﻮﻣﺎﺗﺎﻟﻨﻈﺎﻣﺎﻟﻌﺎﻣﺔ)ﻣﻌﻠﻮﻣﺎﺗﺣﻮﻟﺎﻻﻣﺘﺜﺎﻟ
ﻟﻠﺘﺪﺎﺑﲑﺎﻷﻣﻨﻴﺔﺎﻟﺘﻨﻈﻴﻤﻴﺔ(،ﺈﻋﺎﺪﺔﺎﻟﺘﻌﻴﻴﻦﺈﱃﺈﻋﺪﺎﺪﺎﺗﺎﳌﺼﻨﻊﺎﻻﻓﱰﺎﺿﻴﺔ .
ﻣﺰﺪﻮﺟﺔﺣﺮﺎﺮﻳﺔﻣﻦﺎﻟﻨﻮﻋ K )ﺎﻟﻄﺮﺎﺰ TG267)
ﺻ
ِ
ﻞﺎﳌﺰﺪﻮﺟﺔﺎﻟﺤﺮﺎﺮﻳﺔﺑﺎﳌﻘﺒﺲﺎﳌﻮﺟﻮﺪﰲﺎﻟﻔﺘﺤﺔﺎﻟﻌﻠﻮﻳﺔ.ﻻﻣﺲﺎﳌﺴﺒﺎﺮﺑﺴﻄﺢﺎﻻﺧﺘﺒﺎﺮﺄﻮ
ﺄﻣﺴﻚﺑﻪﰲﺎﻟﻬﻮﺎء.ﺎﻗﺮﺄﺪﺮﺟﺔﺎﻟﺤﺮﺎﺮﺔﻋﲆﺎﻟﺸﺎﺷﺔ)ﺑﺠﺎﻧﺐﺮﻣﺰ TC). ﻮﺈﺬﺎﻟﺰﻣﺎﻷﻣﺮ،ﻓﻤﻜ
ّ
ﻦ
ﻮﺿﻊﺎﳌﺰﺪﻮﺟﺔﺎﻟﺤﺮﺎﺮﻳﺔﻣﻦﻗﺎﺋﻤﺔ Settings ( ﺎﻹﻋﺪﺎﺪﺎﺗ(ﺎﻟﻔﺮﻋﻴﺔ)ﺿﻤﻦ Measurements
( ﺎﻟﻘﻴﺎﺳﺎﺗ((.ﻻﺗﺘﺠﺎﻮﺰﻧﻄﺎﻗﺪﺮﺟﺔﺎﻟﺤﺮﺎﺮﺔﺎﳌﻄﺒﻮﻋﻋﲆﻣﻠﺼﻖﺎﳌﺰﺪﻮﺟﺔﺎﻟﺤﺮﺎﺮﻳﺔ.ﺎﻧﻈﺮﺎﻟﺼﻮﺮﺔ
5،ﻣﺰﺪﻮﺟﺔﺣﺮﺎﺮﻳﺔﻣﻦﺎﻟﻨﻮﻋ K، ﰲﺎﻟﻘﺴﻢﺎﻟﺮﺳﻮﻣﺎﻟﺘﻮﺿﻴﺤﻴﺔ .
ﺎﻟﺘﻌﺎﻣﻞﻣﻊﺎﻟﺼﻮﺮ
ﺎﻧﺘﻘﻞﺈﱃ Gallery ( ﻣﻌﺮﺿﺎﻟﺼﻮﺮ(ﰲﻧﻈﺎﻣﺎﻟﻘﺎﺋﻤﺔ.ﺎﺳﺘﺨﺪﻣﺎﻷﺳﻬﻢﻟﻠﺘﻤﺮﻳﺮﻮ MENU
( ﺎﻟﻘﺎﺋﻤﺔ(ﻟﻔﺘﺢﺎﻟﺼﻮﺮ.ﺎﺿﻐﻂﻋﲆ MENU ( ﺎﻟﻘﺎﺋﻤﺔ(ﰲﺻﻮﺮﺔﻣﻔﺘﻮﺣﺔﳌﺸﺎﻫﺪﺔﺧﻴﺎﺮﺎﺗ
ﺎﻟﺼﻮﺮﺔ.ﺎﺿﻐﻂﻋﲆ MENU ( ﺎﻟﻘﺎﺋﻤﺔ(ﻣﻦﺧﻴﺎﺮ SEND ( ﺈﺮﺳﺎﻟ(ﻟﻨﻘﻞﺎﻟﺼﻮﺮﺔﻋﱪﺧﺎﺻﻴﺔ
Bluetooth® ﺈﱃﺄﺣﺪﺄﺟﻬﺰﺔﺎﳌﺤﻤﻮﻟﺎﳌﻘﱰﻧﺔ)ﺎﻟﻄﺮﺎﺰﺎﻧ TG267 ﻮTG297 ﻓﻘﻂ(.ﺎﺿﻐﻂ
#NAS100021; r. AD/64725/64725; mul
6

FLIR TG267 Specifications

General

Temperature Range	-25°C to 380°C (-13°F to 716°F)
Field of View	57° × 44°
Battery Life	Up to 5 hours
Thermal Sensitivity/NETD	< 70 mK
Image Frequency	9 Hz
Focus	Focus free
MSX (Multi-Spectral Dynamic Imaging)	Yes
On-Screen Emissivity Correction	Yes
Image File Format	JPEG
Laser Pointer	Yes
Drop Test	2 m (6.5 ft)
Weight	0.394 kg (0.87 lb)
Dimensions	210 × 64 × 81 mm (8.3 × 2.5 × 3.2 in)
Operating Temperature Range	-10°C to 45°C (14°F to 113°F)
Storage Temperature Range	-40°C to 70°C (-40°F to 158°F)
IP Rating	IP54
IR Resolution	160 × 120 pixels
Battery Type	Rechargeable Li-ion battery
Emissivity	Adjustable from 0.1 to 1.0
Image Modes	Thermal, MSX
Storage Media	Internal memory
Spectral Range	8–14 µm
