Floe CargoMax XRT - Page 26

26
Cargo Max 8-57 Parts List
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
149-00523-01
RAMP ASSEMBLY
2
2
005-55810-00
FENDER
3 2
Standard: 550-00007-00
Mag: 005-10001-00
TIRE
4 10
Standard: 005-08200-00
Chrome: 550-00016-00
LUG NUT
5 2
(For Mag Wheels Only):
550-00022-00
CENTER HUB
6
1
150-01556-02
TONGUE ASSEMBLY
7
1
551-09901-00
TONGUE JACK
8
4
001-70118-00
3/8-16 x 3-3/4” HEX HEAD CAP SCREW
9
6
001-76071-00
3/8-16 ALUMINUM NYLOCK NUT
10
1
003-01701-00
PLUG HOLDER
11
1
003-40000-00
1-1/8” GROMMET
12
1
004-00407-00
CLASS II COUPLER WITH CHAIN-PIN
13
2
001-70219-00
½-13 x 4” HEX HEAD CAP SCREW
14
2
001-76072-00
½-13 ALUMINUM NYLOCK NUT
15
2
004-00500-00
26” SAFETY CHAIN WITH CLIP
16
2
001-70107-00
3/8-16 X 1-1/4” HEX HEAD CAP SCREW
17
2
001-45165-00
3/8” FLAT WASHER
18
1
150-01558-00
TONGUE CLAMP ASSEMBLY
19
1
149-01702-01
LIMITER STRAP ASSEMBLY
20
1
001-70000-00
TONGUE CLAMP KNOB
21
2
002-09055-00
TRAILER SIDE HINGE
22
4
551-28027-00
AXLE COVER
23
3
001-71212-00
REAR CHANNEL WASHER
24
8
001-70024-00
“D” RING
25
8
005-70006-00
“D” RING TIE DOWN BASE PLATE
26
23
001-03568-00
¼-20 x 1” BUTTON HEAD CAP SCREW
