7
For optimal performance of the axles with electric brakes, the
trailer brakes need to be synchronized with the towing vehicle
brakes, and the break-away system needs to be properly
maintained.
SYNCHRONIZATION
To synchronize the trailer and tow vehicle brakes, make several
full stops from a speed of about 20 mph, and then adjust the
brake controller as required. Repeat as necessary until the
brakes function optimally. With proper synchronization, the
trailer should not yank on the tow vehicle or push on it while
braking.
BREAK-AWAY SYSTEM
Trailers with electric brakes are equipped with a break-away
system that will bring the trailer safely to a stop in the event
that the trailer becomes disconnected while driving.
e break-away system is powered by a battery box that
charges automatically when the 7-way plug is attached to the
tow vehicle. e break-away system also contains a break-
away switch with a removable pin attached to a cable. e pin
must be installed in the break-away switch and the cable must
be attached to the tow vehicle while driving. In the event that
the trailer becomes disconnected from the tow vehicle while
driving, the pin will be removed from the break-away switch,
which will activate the electric brakes.
To test the unit, pull on the cable to remove the pin from the
break-away switch, and verify that the electrical brakes have
been activated. e break-away system should be tested prior
to each trailer outing.
Using your FLOE trailer
Electric Brake Option
Model Dimensions
GVWR
lbs/kgs
Cargo Load
lbs/kgs
Net Wt.
lbs/kgs Standard Tires Upgrade Tire
Max.
tongue wt. -
lbs/kgs
Tire
Speed
Rating
XRT 8-57 8’ x 57” 2140/971 1800/816 290/132 5.30 x 12” -C 5.30 x 12” -C Mag 125/57 65 mph
XRT 9.5-73 9.5’ x 73” 2800/1270 2200/998 480/218 205-75R14 Steel 205-75R14 Alum 220/100 75 mph
XRT 9.5-73 9.5’ x 73” 2990/1356 2380/1080 520/236 205-75R14 Steel 205-75R14 Alum 300/136 75 mph
XRT 11-73 11’ x 73” 2800/1270 2200/998 540/245 205-75R14 Steel 205-75R14 Alum 220/100 75 mph
XRT 11-73 11’ x 73” 2990/1356 2380/1080 580/263 205-75R14 Steel 205-75R14 Alum 300/136 75 mph
XRT 13-73 13’ x 73” 2800/1270 2200/998 570/259 205-75R14 Steel 205-75R14 Alum 220/100 75 mph
XRT 13-73 13’ x 73” 2990/1356 2380/1080 610/277 205-75R14 Steel 205-75R14 Alum 300/136 75 mph
XRT 13-73T 13’ x 73” 2990/1356 2200/998 780/354 205-75R14 Steel 205-75R14 Alum 440/200 75 mph
XRT 13-73T 13’ x 73” 4400/1996 3470/1574 930/422 205-75R14 Steel 205-75R14 Alum 440/200 75 mph
Loading your FLOE trailer
Capacities & Weight Distribution
Trailers cargo load capacity is reduced by the weight of additional options such as Gate Keepers and/or Cargo Covers.
NO
BRAKES
BRAKES
2014
- 2020
2014
- 2020
2014
- 2020
2021
2021
2021
