CONTENTS
This package contains:
● 1 Marble/tile saw with water tube and hose attachment
● 1 Diamond blade 4-1/2” x 7/8”(bore)
● 1 Socket wrench
● 1 Box wrench
● 1 instruction manual
Check the tool and accessories for damage, which could have occurred during transportation.
USAGE TIPS
● Always cut one tile at time.
● Be sure motor has reached full speed before starting to cut tile.
● Let the saw blade run freely for a few seconds before cutting a piece of tile. Switch off immediately
and disconnect the power supply if it makes an unfamiliar sound or vibrates excessively.
● The directional arrow marked on the blade should correspond with the rotation direction of the
motor.
● Ensure that the blade-securing arbor and collars are tight.
● Let the blade come to a complete stop before removing any jammed or cut off material from
around the blade area.
● Never allow the continuous rim blade to run dry. Failure to keep the water on it will result in
possible over-heating of the diamond blade and a poor cut of the tile.
Caution: This tile saw is designed for cutting tile and marble, not for metal, wood or plastic. All
other applications are expressly excluded.
OPERATION OF SAW
Diamond Blade Installation and Removal
Warning: Before installing or removing blade, turn off the power supply. Failure to do so may
result in accidental starting of the tool which may cause serious injury.
● To remove the diamond blade, grip outside flange with box wrench, place socket wrench on
spindle bolt and turn socket wrench clockwise (Figure 1). Remove spindle bolt, outside flange and
blade. Do not remove inner flange (Figure 2).
