REF.
NO.
PART NO.
DESCRIPTION QTY.
1 L52040 SHAFT-primary & secondary chain drive 2
2 14T28MM
SPROCKET-
durakast
(14 tooth, 28mm)(bar chain)(pecans/hzlnts.)
4
12T32MM
SPROCKET-
durakast (12 tooth, 32mm)(bar chain)(walnuts)
4
14T28MMP
SPROCKET-
poly (14 tooth,28mm)(bar chain)(pecans/hzlnts.)
4
12T32MMP
SPROCKET-poly (12 tooth, 32mm)(bar chain)(walnuts)
4
3A F32928R ROLLER-support (bar chain) 2
3B L32920 ROLLER-support (wire chain) 4
4 SR5509 SPROCKET-split (wire chain) 4
5 F64008 PLATE-bearing 2
6 FLC2108 BEARING 2
7 SDS108 BUSHING-sprocket 2
8 60SDS20 SPROCKET-conveyor drive 2
9 L66225 STRAP-conveyor 2
10 F64018 BRACKET-take up bearing 2
11 F10728 REDI BOLT-bearing take up 2
12A HM1149
MOTOR-
secondary chain
(Eaton)(s/n ~1246)(may use HM2149)
1
HM2149 MOTOR-secondary chain (Danfoss)(s/n 1247~) 1
12B HM1149-K SEAL KIT-motor (HM1149) 1
HM2149-K SEAL KIT-motor (HM2149) 1
13 AG2417 IDLER-sprocket 1
14 L65925 BRACKET-conveyor seal 2
15 L31095 SEAL-conveyor (rubber) 2
16 L64835 CLAMPSTRIP-conveyor seal 2
17 L19035
RACEWAY-light & camera wire
(optional light kit)(s/n ~2169)
1
18 L21015 GUARD-light (optional light kit)(s/n ~2169) 1
19 L19055
RACEWAY-light & camera wire
(optional light kit)(s/n ~2169)
1
20 L64915 BRACKET-elevator seal (right) 1
L64935 BRACKET-elevator seal (left) 1
21 L31085 SEAL-elevator (rubber) 2
22 L64905 CLAMPSTRIP-elevator seal 2
23 L60455 ANCHOR-inlet tube chain 1
24 L20080 COVER-elevator access 1
25 L20810 COVER-elevator access 1
26 L66010
ARM-torque
(include 2 of L13015 bushings for s/n ~1246)
1
27 PBC2108 BEARING 2
28 SDS100 BUSHING-sprocket 1
29 50SDS20 SPROCKET-beater drive 1
30 L67400 MOUNT-motor 1
31 CP9118 COUPLER-motor to shaft 1
32A HM1149
MOTOR-
pri. chain & beater (Eaton s/n~1246)(may use HM2149)
1
HM2149
MOTOR-
pri. chain & beater (Danfoss)(s/n 1247~)
1
H25PB007
FLORY INDUSTRIES, INC.
MODEL 850-860 HARVESTER
