RE
F.
NO.
PART NO.
DESCRIPTION QTY.
32B HM1149-K SEAL KIT-motor (HM1149) 1
HM2149-K SEAL KIT-motor (HM2149) 1
33 AG2416 IDLER-chain 1
34 50BS24100 SPROCKET-beater driven 1
35 PBC2100 BEARING-beater shaft 2
36 L61340 BRACKET-bearing take up 2
37 VL3850 VALVE-flow control 1
38 L31130 SEAL-primary chain return 1
39 F6012 CLAMPSTRIP-seal 2
40 L31575 SEAL-lower elev. (s/n 1434 ~) 1
L31516
SEAL-lower elev. twin rod (s/n 2210 ~)
1
41 RL1080 ROLLER-nose (lower elevator) 2
42 L20090 COVER-elevator access *
*Quantity required
s/n ~2026 = 2, s/n 2027~ = 4
43 F20078 COVER-elevator access 4
44 L68705 ELEVATOR/CONVEYOR-(s/n ~1334) 1
L68715 ELEVATOR/CONVEYOR-(s/n 1343-1608) 1
L68725 ELEVATOR-(s/n 1624~) 1
45 L13015 BUSHING-torque arm (s/n 1247~) 2
46 F10728 REDI BOLT-bearing take up 2
47 CA6012-2 CLAMP-hose (3/4” twin) 3
48 CA6008-2 CLAMP-hose (1/2” twin) 1
49 L67805 MOUNT-motor 1
50 L65405 BRACKET-seal (L41875)(s/n 1343-1362) 1
51 L20615 COVER-elevator side seal bracket 2
52 L68735 CONVEYOR-low position (s/n 1624~) 1
L68745 CONVEYOR-high position (s/n 1624~) 1
53 88176 LIGHT-rear (optional light kit)(s/n ~2169)** 1
54 112201 SOCKET, SMV mount (s/n 2185~) 1
**For s/n 2185~, optional light to be mounted in shield L20856
H25PB007
FLORY INDUSTRIES, INC.
MODEL 850-860 HARVESTER
