Flory 860 - Page 39

REF.
NO.
PART NO.
DESCRIPTION QTY.
1 L50640 AXLE-rear (s/n ~1794)(2102 ~ s/n) 1
2 106169K SPINDLE-rear (welded) 2
3 106686 HUB-rear wheel (includes ref. nos. 4-10) 2
4 CR20044 SEAL-hub 2
5 LM501349 CONE-bearing 2
6 LM501310 CUP-bearing 2
7 105144 BOLT-lug 12
8 LM67010 CUP-bearing 2
9 LM67048 CONE-bearing 2
10 103969 CAP-dust 4
11 104581 WASHER-spindle 4
12 103289 NUT-spindle 4
13 106809-R1 WHEEL-rear 2
14 31X1350-15 TIRE-rear 2
15 K11246 ROD-depth gauge 2
16 F11008 BOLT-front spindle 2
17 F60408 SPINDLE ASSEMBLY-front (right) 1
F60468 SPINDLE ASSEMBLY-front (left) 1
18 105708K SPINDLE-front (welded) 2
19 104682 HUB-front wheel (includes ref. nos. 20-26, 10) 2
20 CR17617 SEAL-hub 2
21 LM48548 CONE-bearing 2
22 LM48510 CUP-bearing 2
23 5081 BOLT-lug 10
24 D3055 NUT-lug 10
25 LM67010 CUP-bearing 2
26 LM67048 CONE-bearing 2
27 106482 WHEEL-front 2
28 27X950-15 TIRE-front 2
H25PB011
FLORY INDUSTRIES, INC.
MODEL 850-860 HARVESTER
39
