REF.
NO.
PART NO.
DESCRIPTION QTY.
1 GB1131 GEARBOX 1
2 HG5010 HOUSING 1
3 BT5010 BOLT-housing 8
4 PG5010 PLUG-vent 1
5 PG5011 PLUG-oil 4
6 MK2600 KIT-shim UAR
7 BR1011 BEARING-cross shaft (ball bearing) 1
8 SF5010 SHAFT-cross 1
9 SL5010 SEAL-cross shaft 2
10 RN7010 SNAP RING-cross shaft 2
11 MK2601 KIT-shim UAR
12 SF5011 SHAFT AND GEARS (pinion shaft and both gears) 1
13 SL5011 SEAL-pinion shaft 1
14 RN7011 SNAP RING-pinion shaft 1
15 BR4011 BEARING-pinion shaft (tapered roller bearing) 1
16 RN7012 SNAP RING-pinion shaft 2
17 BR4012 BEARING-pinion shaft (tapered roller bearing) 1
18 BR4013 BEARING-cross shaft (tapered roller bearing) 1
19 CV5010 COVER-end cap 1
H25PB005
FLORY INDUSTRIES, INC.
MODEL 850-860 HARVESTER
41
