REF.
NO. PART NO.
DESCRIPTION QTY.
1A HP4233 PUMP, double system hyd. ( ~ s/n 2076) 1
HP2823 PUMP, double system hyd. ( s/n 2077 ~) 1
1B HP4223-K SEAL-KIT, pump, with wearplate ( s/n 1624 ~) 1
HP1061K SEAL-KIT, pump, w/o wearplate ( s/n 2077 ~) 1
2 VL5184 VALVE-control (not shown) 1
VL5286 VALVE-control (not shown) (s/n 1987~) 1
3 L29515 BOX-switch 1
4 L29525 COVER-switch box 1
5 L20305 COVER-solenoid valve 1
6A SW2010 SWITCH-toggle (dpst) 1
6B SAN105 BOOT-rubber 1
7A S2098 SWITCH-toggle (spst) 1
7B SAN105 BOOT-rubber 1
8A SW2056 SWITCH, toggle (dpdt) 1
8B SAN105 BOOT-rubber 1
9 RB7010 GROMMET- rubber 1
10 L67775 MOUNT- quick coupler (Required when retrofitting) 1
11 L60005-066 MOUNT-valve (This weld bracket is required for 1
retrofitting machines from s/n ~1608)
12 L67776 MOUNT- cart manifold (s/n 1987~) 1
13 CP8100 COUPLER, pump half (s/n 2077 ~) 1
14 MF7286 MANIFOLD, HIC (not shown) (s/n 1987~) 1
15 FD285 DECAL, switch box (not shown) 1
16 PG6070 PLUG, linear actuator (not shown) 1
17 GS0086 GASKET, switch box 1
L99045 OPTIONAL POWER PAK KIT (s/n 1624~)
See hydraulic schematic Ref. # 50-56 for hose detail.
See electrical schematic for wiring detail.
H25PB017
FLORY INDUSTRIES, INC.
MODEL 850-860 HARVESTER
