Flory 860 - Page 61

REF.
NO.
PART NO.
DESCRIPTION QTY.
1A HP3233 PUMP-systems hydraulic (single / standard) 1
1B HP2155-K SEAL KIT-pump 1
2 H12412-2 HOSE-pump to relief valve (41”) 1
3 H2076S HOSE-tank suction to pump (76”) 1
4 VL7080 VALVE-relief 1
5 H12662 HOSE-relief valve to tank return 1
6 H12252-3 HOSE-relief valve to p/u belt motor (25”) 1
7A HM2149 MOTOR-shaft drives 3
7B HM2149-K SEAL KIT-motor 3
8 L67205 TANK-oil 1
9 H121222-3 HOSE-p/u belt motor to primary d/c motor (122”) 1
10 310DB CYLINDER-telescoping hitch 1
11 H82802 HOSE-tractor to cylinder (280”) 1
12 H82692 HOSE-tractor to cylinder (269") 1
13 H12352-2 HOSE-primary d/c motor to flow control (35”) 1
14 H12772 HOSE-flow control to secondary d/c motor (77”) 1
15 H12852 HOSE-secondary d/c motor to flow control (85”) 1
16 H12422 HOSE-flow control to tank return (42”) 1
17 VL3850 VALVE-flow control 1
18 VL0020 VALVE-air bleed 1
19 H61041-2 HOSE-air bleed valve to tank (104”) 1
HYDRAULIC SCHEMATIC (s/n 1234-1238)
H25PB018
FLORY INDUSTRIES, INC.
MODEL 850-860 HARVESTER
61
