REF.
NO. PART NO.
DESCRIPTION QTY.
1A HM2149 MOTOR-hydraulic (p/u, prim. & elv.) 3
HM2149 MOTOR-hydraulic (paddle sweeps)(s/n ~1794) 2
1B HM2149-K SEAL KIT-motor (p/u, prim. & elv.) 3
HM2149-K SEAL KIT-motor (paddle sweeps)(s/n ~1794) 2
2 VL3850 VALVE-flow control (standard) 1
3A HP3233 PUMP-systems hydraulic (single / standard) 2*
3B HP2155-K SEAL KIT-pump 2*
4 DRL4-ASN FILTER-return 1
5 L67205 TANK-oil 1
6 VL7080 VALVE-relief 1
7 310DB CYLINDER-telescoping hitch 1
8 L67775 MOUNT-coupler *(Qty 1 - standard, Qty 1 - power pak) 2*
9 VL5184 VALVE-3 bank (s/n 1624~1986) (power pak) 1
VL5286 VALVE-2 bank (s/n 1987~) (power pack) 1
VL5986 VALVE-4 bank (s/n 1987~) (Herbs cart) 1
10 RDRS197530 VALVE-flow control (paddle sweep) 1
11A HM3149 MOTOR-hydraulic (p/u)(s/n 1795~) 1
11B HM3149K SEAL KIT-motor (p/u)(s/n 1795~) 1
12 MF7286 MANIFOLD, HIC (s/n 1987~) 1
13A HP4233* PUMP, double system hyd. (~ s/n 2076) 1
HP2823** PUMP, double system hyd. ( s/n 2077 ~) 1
13B HP4223-K SEAL-KIT, pump, with wearplate ( s/n 1624 ~) 1
HP1061K SEAL-KIT, pump, w/o wearplate ( s/n 2077 ~) 1
25 Tank suction pump inlet
26 Pump outlet to relief port "P"
27 Relief "P" port to P/U motor rear port
28 Relief "T" port to return filter tee
29 P/U motor front port to prim. motor front port
30 Prim. mtr. rear port to elev. flo-con "IN"
31 Elev. flo-con "CF" port to elev. motor top port
32 Elev. motor bottom port to flo-con "EX" port tee
33 Flow cont. "EX" port tee to tank filter tee
34 Tractor to top quick connector
35 Tractor to bottom quick connector
36 Tractor to hyd. hitch cyl. base end
37 Tractor to hyd. hitch cyl. rod end
38 Elev . flo-con. "EX" port tee to sweep flo-con "IN"
HYDRAULIC SCHEMATIC (s/n 1247~)
*NOTE (3A-3B) Qty 1 - standard, Qty 1 - power pak
*NOTE: Front and rear sections are 2.32 CIR
**NOTE: Front section = 2.75 CIR, Rear section = 2.32 CIR
H2
520011
FLORY INDUSTRIES, INC.
MODEL 850-860 HARVESTER
