Flotrol F60 - Brining System Parts List

Page 17
Assembly Drawings and Part Numbers
Large Brining System Assembly Parts List
MODEL F60
Item No. Quantity Part No. Description
1 1 052-00081-00 Stem Guide Assembly
2 1 068-00011-00 Retaining Ring
3 1 058-00006-00 Spring
4 2 066-00005-00 Screw
5
1 052-00280-00 Brine Valve Body (NPT)
1 052-00064-00 Brine Valve Body (BSP)
6 1 099-00717-00 Brine Valve Stem Assembly
7 1 060-00049-00 O-Ring -124
8 1 052-00298-00 Brine Tube Assembly
9 2 052-00296-00 Tube Fitting
10 6 066-00029-00 Screw-Hex, HD
11 1 052-00066-00 Injector Cap
12 3 060-00023-00 O-Rings -116
13
1 051-00176-00 10
#
Injector Nozzle
1 051-00174-00 8
#
Injector Nozzle
14 1 052-00065-00 Injector Body
15
1 051-00175-00 10
#
Injector Throat
1 051-00172-00 8
#
Injector Throat
16 1 052-00074-00 Pipe Plug-1/2" (NPT)
17 1 052-00068-00 Injector Plug
18 1 068-00008-00 Retaining Ring
19 1 051-00182-00 Spring Clip
20 1 060-00058-00 RFC Washer-10 gpm
21 1 051-00185-00 Filter Sheet
22 1 060-00046-00 O-Ring-AS020
23
1 052-00283-00 1" RFC Housing (NPT)
1 052-00076-00 1" RFC Housing (BSP)
24 1 051-00325-00 1"Female NPT*1"Slip
25 1 051-00119-00 1” Air Check
Bold faced items are recommended spare parts.
