370542 D/GB
32
GB
order no.
figure
item
description
BSM 150
370545
BSM 150 A
370540
BSM 150 A/pol
370530
1
1A
Belt cover incl. hinge, screws (4)
ball handle (3), ring (2)
370548 370548 370548
1
5A
Rubber seal 370606 370606 370606
1
8
Side panel
Spacer M6 (6)
Hex head screw M6x16 (7)
370607 370607 370607
1
13
Stop plate f. spark protector
incl. Washer (37) and
Hex head screw M8x16 (15)
370564 370564 370564
1
14
Washer for M8 006419 006419 006419
1
16
Hex head screw M8x20 003627 003627 003627
1
17
Hex nut M8 003658 003658 003658
1
18
Spark protector, full set
Nut M6 (9), hinge (10),
Screw M4x10 (11)
Screw M6x45 (12)
370566 370566 370566
1
20
Hex head screw M8x25 003236 003236 003236
1
21
Frame 370608 370608 370608
1
22
Drive wheel vulcanized, convex
370568 370568 370568
1
23
Eccentric cam lever 370569 370569 370569
1
24
Spring washer 370615 370615 370615
1
25
Spring 370571 370571 370571
1
26
Sanding belt Grit 40
Sanding belt Grit 60
Sanding belt Grit 80
Sanding belt Grit 100
Sanding belt Grit 120
f. high grade steel and cast iron
Sanding belt Grit 40
Sanding belt Grit 60
Sanding belt Grit 80
Sanding belt Grit 120
371125
371126
371127
371128
371129
371828
371829
371830
371831
371125
371126
371127
371128
371129
371828
371829
371830
371831
371125
371126
371127
371128
371129
371828
371829
371830
371831
1
Graphite protection layer
500x150 mm
370619 370619 370619
1
28
Switch, with
Seal and
Housing
370573
370574
370528
370572
370574
370528
370527
370574
370521
1
31
Motor
5HP 3PH 400V 50HZ, incl.
Key (32) for shaft, Fixing screw
(29) and Seal (30)
Fan wheel
Cover cap
370575
370559
370599
370575
370559
370599
370554
370559
370599
1
33A
Pedestal upper lid 370609 370609 370609
1
34
Washer for M8 006419 006419 006419
1
35
Hex head screw M8x25 003236 003236 003236
1
36
Hex nut M12 003930 003930 003930
