JetFlow Relay User Instruction – AIIOM000287
18
Name
Description
Additional Information
LED Color
Code
Relay Type Unknown
JetFlow relay type not recognized.
Check the model code, update
embedded software, verify
mounting configuration is correct.
Table 10: Logix 3800JF Model Code
Selection
Description
Code
Base Model
Logix 3800 Series
38
Communication
HART
1
2
Housing
Aluminum – Ex d JetFlow
1JF
Certifications
General Purpose
14
ATEX / IECEx ,Ex db, Ex tb,FM/US/Canada Ex Proof Class I Div 1 Gp B-D (A)Ex db,
Dust Ignition Proof Class II,III Gp E-G (A)Ex tb ,Type 4x, IP66
43
Threaded Connections
Mounting: 5/16" 18 UNC, Pneumatics: 1/4" NPT, Conduit: 1/2" NPT, Vents 1/4" NPT
E
Mounting: M8 x 1.25, Pneumatics: 1/4" NPT, Conduit: M20 x 1.5, Vents 1/4" NPT
M
Mounting: M8 x 1.25, Pneumatics: G1/4", Conduit: M20 x 1.5, Vents G1/4"
G
Actuation Medium
Air
A
Relay Type
JetFlow Relay J0, Cv 9, Tubing Size 0.75", Vent and Supply Port Size 0.75"
J0
JetFlow Relay J1, Cv 9, Tubing Size 1.0", Vent and Supply Port Size 1.0"
J1
JetFlow Relay J2, Cv 21, Tubing Size 1.5", Vent and Supply Port Size 1.5"
J2
JetFlow Relay J3, Cv 50, Tubing Size 2.0", Vent and Supply Port Size 2.0"
J3
Action
Standard, Double Acting (Four-way)
4
Pressure Gauges
Standard Nickel Plated, psi (bar/kPa) Sealed and purged
1
Standard Nickel Plated, psi (kg/cm2 ) Sealed and purged
2
Stainless Steel, psi (bar/kPa) Sealed and purged
3
Stainless Steel, psi (kg/cm2 ) Sealed and purged
4
UCC Press Test Plug, 1/8" NPT
A
Valve, Tank, Schrader 645A
B
Gauge Orientation
Gauges oriented for display on the right side of the positioner
R
Diagnostics
Pro-Diagnostics (Full Functionality)
1
Display
LCD
1
Feedback Shaft
(Positioner to JetFlow)
DD - 316 Stainless Steel Shaft (Reverse Spring for long stroke)
7
Mounting
Remote Mount Option
R
Special Options
No Special Options
00
Special Options
ZZ
1 HART 6 standard. Can be configured as HART 7 in the field.
EX:
3821
JF
- 43EA
- J241R
- 11
7R - 00
