P a r ts List — FLOWTRON ELECTRIC L E A F - E ATER #LE-900F
Ref. # Part # Description Qty.
1 355 2118 FUNNEL 2
2 245 6237 P28 SCREW, SHT. MTL., PAN HD., PHIL, #8 X 1/2, BLK. 2
3 345 2285 P42 SCREW, PAN HD., PHIL, #10 X-3/4 2
4 345 2285 P29 SCREW, PAN HD., PHIL, #8 X 5/8 8
5 396 2599 LEG HUB SPACER 2
6 355 2117 MAIN HOUSING 2
7 305 3015 JUMPER WIRE ASSY. 1
8 352 2138 MOTOR SUPPORT PLATE 1
9 355 2116 BULKHEAD 1
10 396 2877 PO1 CUTTING LINE 2
11 396 2438 HANDLE GRIP 2
12 355 3150 MULCHING DISC 1
13 345 2978 SCREW, PHIL, HEAD, #10-24 x 5/8 2
14 245 6272 P04 #10 FLAT WASHER 2
15 352 3149 CUTOFF BRACKET 1
16 567 4675 ‘‘O’’ RING 1
17 368 2766 P1 LEG, LEFT 1
18 368 2767 P1 LEG, RIGHT 1
19 355 3105 SPACER, CIRCUIT BREAKER 1
20 394 3500 CIRCUIT BREAKER 1
21 355 2135 STORAGE DOOR 1
22 312 2517 POWER CORD 1
23 355 2115 MOTOR HOUSING 1
24 343 2570 BAFFLE (NOT SHOWN) 1
25 379 3449 MOTOR 1
26 355 2134 LEG KNOB 2
27 355 2133 LEG HUB 2
28 367 2574 FRICTION PAD 2
29 355 2555 ADJUSTMENT KNOB 1
30 355 2130 SWITCH COVER 1
31 305 1779 SPINNER HEAD ASSEMBLY 1
32 394 3014 SWITCH, ON/OFF 1
33 345 2285 P34 SCREW, PAN HD., PHIL, #8 X 1-1/4 6
34 367 3011 FILTER ELEMENT, REMOVABLE 1
35 396 2136 BUNGEE CORD 1
36 595 1506 WIRE CONNECTOR 1
37 345 1683 JAM WASHER, SPINNER (NOT SHOWN) 1
38 369 1689 INSERT, SPINNER (NOT SHOWN) 1
39 345 3199 TRHEADED STUD 1
40 357 3197 NUT
41 355 2816 LEG CLAMP, UPPER 1
42 355 2817 LEG CLAMP, LOWER 1
43 245 6225 P33 SCREW, PAN HD., PHIL PARK, #8-32 X 5/8 4
44 245 6267 P44 NUT, HEX STL, PARK, #8-32, 11/32 4
45 357 3151 OWNER’S MANUAL 1
FLOWTRON LEAF-EATER THE ULTIMATE MULCHER
