1551A Ex/1552A Ex

Calibration Manual

To change the batteries, see Figure 1:

1. Use a flat-blade screwdriver to remove the battery door screw.

2. Remove the battery door to access the three AAA batteries.

3. Replace only with approved AAA batteries listed in this document. See Table 11.

Any substitution voids the Product safety rating.

4. Make sure the battery polarity is correct.

5. Replace the battery door and install the screw.

gjo003.eps

Figure 1. Battery Replacement

Table 11. Approved Batteries

Battery Manufacturer Type

Duracell LR03/MN2400

Rayovac LR03/824

Energizer LR03/E92

Alkaline AAA

Panasonic LR03X

Other manuals for Fluke 1551A Ex

Questions and Answers:

Need help?

Do you have a question about the Fluke 1551A Ex and is the answer not in the manual?

Measurement Specifications

measurement range	−50 °C to 160 °C
accuracy	±0.05 °C
resolution	Selectable (0.1, 0.01, 0.001) factory default is 0.01

Environmental Specifications

operating temperature range	−10 °C to 50 °C
humidity range	0 to 95 % RH Non-condensing
storage temperature range	−20 °C to 60 °C

Power Specifications

power source	3 AAA alkaline batteries
battery life	Approximately 300 hours without back light
battery save range	Selectable from 1 to 30 minutes or can be disabled

Weight and Dimensions

Measurement Specifications

measurement range	−80 °C to 300 °C
accuracy	±0.05 °C
resolution	Selectable (0.1, 0.01, 0.001) factory default is 0.01

Environmental Specifications

operating temperature range	−10 °C to 50 °C
humidity range	0 to 95 % RH Non-condensing
storage temperature range	−20 °C to 60 °C

Power Specifications

power source	3 AAA alkaline batteries
battery life	Approximately 300 hours without back light
battery save range	Selectable from 1 to 30 minutes or can be disabled

Weight and Dimensions
