5 220A
Instruction Manual
5-28
Table 5-8. A7 Output PCB Assembly
Reference
Designator Description
Fluke
Part No.
Total
Quantity
H1 Screw, Machine, PH, P, Steel, 4-40 x 0.375 152124 2
H2 Washer, Lock, Internal, Steel, #4 110403 2
H3 Nut, Hex, S. Steel, 4-40 147611 2
H4 Screw, Machine, PH, P, Steel, 6-32 x 0.250 152140 2
H5 Screw, Machine, PH, P, Steel, 6-32 x 0.750 114223 8
H6 Washer, Lock, Internal, Steel #6 110338 1
H7 Nut, Hex, Steel, 6-32 110551 1
H8 Screw, Machine, PH, P, Steel, 8-32 x 0.35 114124 8
H9 Nut, Macine, Hex, Steel, 8-32 110544 2
H10 Screw, Machine, PH, P, Steel, 4-40 x 0.312 152116 1
MP1 Output, PCB Bracket 489567 1
MP2 Fin, Heatsink 489880 1
MP3 Plate, Temperature Sense 489898 1
MP4 Bus, Output PCB 502161 2
MP5 Output Chamber 485961 1
MP6 Defector Fin, Heatsink 489508 1
MP7 Spacer, Swaged, Hex, Brass, 6-32 x 0.625 181727 2
MP8 Spacer, Swaged, Round, Brass, 6-32 x 0.187 351882 8
MP9 Insulated Part, Transistor, Aluminum, TO-3 477802 4
MP10 Socket, Single, PCB, For 0.018 – 0.040 Pin 348201 8
MP11 Heat Dissipator, W/BEO Washer, TO-5 407262 1
MP12 Space, Transistor Mount, DAP 152207 1
MP13 Washer, Flat, Nylon, 0.257 ID x 0.500 x 0.093 682385 1
MP14 Plastic Part, Hole Plug, Polyethylene, 0.312 187799 2
MP15 Washer, Shoulder, Nylon, 0.113, 0.345 485417 3
MP16 Insulated Part, Transistor, Film, TO-220 412809 1
Q101
h Transistor, SI, BV = 45 V, 27 W, TO-220
325753 1
Q102
h Transistor, SI, BV = 45 V, 30 W, TO-220
325761 1
Q103, Q104
h Transistor, SI, BV = 60 V, 200 W, TO-3
483222 2
Q105, Q106
h Transistor, SI, PNP, Small Signal
483230 2
Q107
Resistor, CF, 1 k, ±5 %, 0.25 W
402586 1
R101 – R107
Resistor, CF, 1 k, ±5 %, 0.25 W
343426 7
R108, R109
Resistor, CC, 5.1 Ω, ±5 %, 0.5 W
177147 2
R110 – R113
Resistor, 0.086 Ω, ±1 %, 4-Terminal, 10 W, 50 PPM
490771 4
R114, R115
Resistor, WW, 2.4 Ω, ±5 %, 2 W
219337 2
S101
Thermo, NO230±8F, NC200±8F, 15 A/120 V ac
344002 1
TP1 – TP7 Terminal, Un-insulated, Feed-through, Hole, Turret 179283 7
XQ101, XQ102 Socket, Transistor, 3-Pin 402958 2
h Indicates a static-sensitive part.
To Next Page
