5 220A
Instruction Manual
1-4
Table 1-2. Specifications (cont.)
General
Load Capability Drives all resistive and capacitive loads consistent with current and
compliance voltage capability. For inductive loads greater than
1 µH and less than maximum inductive loads, output current is
limited to 16 A rms (22.6 A peak)
Maximum Isolation Voltage ±20 V dc or 20 V ac rms
Temperature Range Operating: 0 °C to 50 ° C
Storage: +20 °C to 56 °C
Relative Humidity 50 % to 50 °C, 75 % to 40 °C, 95 % to 25 °C
Altitude Operating: 0 ft to10,000 ft
Non-operating: 0 ft to 40,000 ft
Vibration 2 g maximum, 5 Hz to 55 Hz for 15 minutes
Shock 15 g maximum, half sinewave
Power Requirements 100, 110, 115, 120, 200, 220, 230, or 240 V ac ±10 %, switch-
selectable, 50 Hz to 60 Hz, 300 W
Weight 27 kg (50 lb)
Dimensions 17.8 cm H x 43.2 cm W x 55.9 cm D (7 in H x 17 in W x 22 in D),
case only (See Figure 1-1).
Protection Safety Class 1 Relates solely to insulation or grounding properties as defined in
IEC 348.
