List of Replaceable Parts
Service Centers
5
5-5
Table 5-1. 5220A Final Assembly (cont.)
Reference
Designator Description
Fluke Part
No.
Total
Quantity
H11 Washer, Lock, Internal, Steel, #4 110403 2
H12 Nut, Machine, Hex, Steel, 4-40 110635 2
H13 Screw, Machine, PH, P, Steel, 6-32 x 0.500 152173 13
H14 Nut, Machine, Hex, BR, 1/4-28 110619 9
H15 Washer, Shoulder, Fiber, 0.250 ID 110833 4
H16 Screw, Machine, PH, P, Steel, 8-32 x 0.500 159749 5
H17 Nut, Machine, Hex, Steel, 8-32 110544 10
H18 Screw, Machine, PH, P, Steel, 10-32 x 0.375 114314 16
H19 Washer, Flat, Steel, 0.265, 0.500, 0.031 110718 4
H20 Washer, Flat, Teflon, 0.366 x 0.266 x 0.050 543314 4
H21 Screw, Machine, PH, P, Steel, 6-32 x 0.625 152181 8
H22 Screw, Machine, PH, P, Steel, 6-32 x 1.500 114181 4
H23 Screw, Machine, PH, P, Steel, 8-32 x 0.375 114124 14
H24 Screw, Machine, PH, P, Steel, 10-32 x 0.625 114066 4
H25 Washer, Lock, External, Steel, 0.500 175943 1
MP1 Panel, Front 479618 1
MP2 Corner Handle, Front, 7 in 394320 2
MP3 Cover, Top 522524 1
MP4 Bracket, Front Panel 486068 2
MP5 Cover, Power Supply 489500 1
MP6 M07-800-415 Decal Covers, Plastic 394403 4
MP7 Plastic Part, Hole Plug, Polyethylene, 0.312 187799 7
MP8 Cover Plate, Digital Connector 502781 1
MP9 Side Trim-21 in 526004 2
MP10 Panel, Rear 485888 1
MP11 Shim, Rear Corner 486050 2
MP12 Corner, Rear 486076 2
MP13 Decal, Rear 502799 1
MP14 Plate, Rear Output 485995 1
MP15 Plate, Front Output 485987 1
MP16 Output Bus, Minus 489526 1
MP17 Output Bus, Plus- Forward 486534 1
