Table 5-1. 5220A Final Assembly (cont.)
Reference
Designator Description
Fluke Part
No.
Total
Quantity
MP18 Output Bus, Plus- Aft 486542 1
MP19 Output Bus, Spacer 486559 1
MP20 Assembly, Red 10-32 Binding Post Bracket 794404 2
MP21 Assembly, Black 10-32 Binding Post Bracket 794412 2
MP22 Shunt Bus, Minus 490524 1
MP23 Shunt Bus, Plus 497974 1
MP24
1
Banana Jack, Panel 101550 4
MP25 Spacer, Round, Nylon, 6-32 x 1.063 104174 4
MP26 Bracket, Fan & Power Supply 485953 1
MP27 Cable Tie, 4.0 Length, 0.100 Width, 0.75 Diameter 172080 2
MP28 Binding Post Part, Head, Brass, 1/4-28 102889 1
MP29 Bushing, Snap-in, Nylon, 0.250 ID 102996 1
MP30 Terminal, Insulated, Standoff, Bifurcated 271650 2
MP31 Power Plug, Panel, 6 A, 250 V, 3-wire 284166 1
MP32 Card Guide, Nylon, 4.50 x 0.076 2-snap 256461 12
MP33 Binding Post, Brass, 1/4-28 102707 1
MP34 Holder Part, Fuse, Cap, 1/4 x 1-1/4 460238 1
MP35 Heatsink, Diode 502179 1
MP36 Insulating Part, Diode, Silicone, Washer 500785 4
MP37 Bus, Capacitor 497982 1
MP38 Chassis Side, Left 485896 1
MP39 Chassis Side, Right 485904 1
MP40 Chassis, Bottom 485912 1
MP41 Bulkhead, Front 485920 1
MP42 Bulkhead, Rear 485938 1
MP43 Partition, Rear 485946 1
MP44 Capacitor Tray 486035 1
MP45 Plate, Front Input 485979 1
MP46 Assembly, Red 6-32 Binding Post Bracket 794453 1
MP47 Assembly, Black 6-32 Binding Post Bracket 794461 1
MP48 Fan Accessory, Filter, AL with Foam 542118 1
MP49 Cover, Bottom 522532 1
