Fluke 5220A - Page 79

List of Replaceable Parts
Service Centers
5
5-7
Table 5-1. 5220A Final Assembly (cont.)
Reference
Designator Description
Fluke Part
No.
Total
Quantity
MP50 Foot, Bail Stand 292870 4
MP51 Spacer, Capacitor 489484 2
MP52 Filter, Retainer 576967 1
MP54 Nameplate, 0.350 x 1.3, Serial Number 472795 1
MP55 Cover, Shunt 489948 1
R2, R5 Resistor, CC, 100, ±10 %, 2 W 109934 2
TM1 5220A Instruction Manual 491936 1
VR1, VR2
2
Zener, Transient Suppressor, 7.5 V, 10 % 904896 2
W1 Line Cord, 5-15/IEC, 3-18 AWG, SVT, 7.5 ft 284174 1
W2 Cable, Fan/Power 491308 1
W3 Fan-Cable 629188 1
XF1 Holder Part, Fuse, Body, 1/4 x 1-1/4, 5 x 20 mm 460329 1
XF2, XF3 Fuse, Clip, PCB, 1/4 x 1-1/4 756460 4
Not Shown Recommended Spare Parts Kit 756460 -
h Indicates a static-sensitive part.
1. This item consists of a plug, a washer, and a hex nut.
2. These parts are located on the A1 Motherboard pcb assembly schematic.
