Table 5-4. A3 Capacitor Bus PCB Assembly
Reference
Designator Description
Fluke
Part No.
Total
Quantity
C1 – C8 Capacitor, AL, 50,000 µF, +100-10 %, 15 V, Hi Term 432525 8
CR1, CR3 Diode, SI, 50 PIV, 20.0 A 483206 2
CR2, CR4 Diode, SI, 50 PIV, 20.0 A 483214 2
F2, F3 Fuse, 0.25 x 1.25, 30 A, 32 V, Fast 500793 2
H14 Nut, Machine, Hex, BR, ¼-28 110619 9
H15 Washer, Shoulder, Fiber, 0.250 ID 110833 4
H16 Screw, Machine, PH, P, Steel, 10-32 x 0.375 159749 5
H17 Nut, Machine, Hex, Steel, 8-32 110544 10
H18 Screw, Machine, PH, P, Steel, 10-32 x 0.375 114314 16
H19 Washer, Flat, Steel, 0.265, 0.500, 0.031 110718 4
H20 Washer, Flat, Teflon, 0.366 x 0.266 x 0.050 543314 4
MP35 Heatsink, Diode 502179 1
MP36 Insulation Part, Diode, Silicone, Washer 500785 4
MP37 Bus, Capacitor 497982 1
R2, R5 Resistor, CC, 100, ±10 %, 2 W 109934 2
XF2, XF5 Fuse, Clip, PCB, 1/4 x 1-1/4 756460 4
