Fluke PM 5136 - Technical Specifications; Frequency Characteristics; Resolution and Setting Errors; Output Characteristics

3
Model PM 5136 PM 5138A PM 5139
Frequency characteristics
Nominal Range 0.1 mHz – 5 MHz 0.1 mHz - 10 MHz 0.1 mHz – 20 MHz
Operational Range
Sine, pos/neg pulse 5 MHz 10 MHz 20 MHz
Square wave 5 MHz 10 MHz 20 MHz
Triangle 500 kHz 500 kHz 500 kHz
Pos./neg. sawtooth 20 MHz 50 kHz 50 kHz
Sine … , triangle pulse 50 kHz
Haversine 50 kHz
4_ digits, max. 0.1 mHz
Resolution 10 Hz (f
C
>200kHz)
*3
Setting error ± 2 x 10
-6
(± 2 ppm)
(f
C
≥5MHz) (f
C
>10MHz)
Residual FM deviation <10ppm, 1ppm typical <10ppm, 1ppm typical
(measuring bandwidth
10Hz-20kHz) <100Hz, 13Hz typical (f
C
≤5MHz) (f
C
≤10MHz)
<100Hz, 13Hz typical <100Hz, 13Hz typical
Phase noise at 1kHz < -80dBc/Hz
distance from carrier
Temperature coëfficient <±0.2ppm / K
Aging <±1ppm / year
Drift <±0.3ppm in 7 hours
Synchronization by an f
REF
=10MHz/N, N=1, 2, 3...10
external reference
Output characteristics
Main Output
Connector BNC socket On front
Impedance 50Ω 50Ω or 600Ω 50Ω or LOW Z
O
Load capability Short circuit proof
Max. external voltage ±15V < 3min 50Ω: ±15V 50Ω: ±15V < 3min
600Ω: ±24V LOW Z
O
: ±12V < 3min
AC voltage independent of DC setting within: ….
Ranges ± 10V window ± 20V window ± 10V window
I resolution 1 mV 0 - 0.200 Vpp 0 - 0.400 Vpp 0 - 0.200 Vpp
II resolution 10mV 0.20 - 2.00 Vpp 0.40 - 4.00 Vpp 0.20 - 2.00 Vpp
III resolution 100 mV 2.0 - 20.0 Vpp 4.0 - 40.0 Vpp 2.0 - 20.0 Vpp
Accuracy for AC voltages > 10mVpp > 20mVpp > 10mVpp
Basic setting error
*2
±2.0%, 1Hz < f
C
< 200kHz
Amplitude flatness
*2
f
C
: 1Hz-200kHz ±0.03dB ±0.03dB ±0.03dB
f
C
: 200kHz -5MHz ±0.07dB ±0.07dB ±0.07dB
f
C
: 5MHz -10MHz ±0.1dB ±0.1dB
f
C
: 10MHz -20MHz ±0.2dB
DC voltage independent of AC setting within: …
± 10V window ± 20V window ± 10V window
Range (open circuit) ±10V resolution 100mV
Error limits
*2
±2.0% ±50mV ±2.0% ±100mV ±2.0% ±50mV
TTL Output 0/5V, Z
0
=50Ω BNC on rear panel
Fan-out > 4 TTL inputs
