Fluke PM 5136 - Waveform and Modulation Specifications; Waveform Details

4
Model PM 5136 PM 5138A PM 5139
Waveforms
Asymmetrie
f
C
≤ 20kHz 1% - 99%, resolution 1% sine, square, triangle, pos./neg. pulses
f
C
: 20kHz - 5MHz 20% - 80%, resolution 1% square, pos./neg. pulses
Sinewave
Frequency range 0.1 mHz – 5 MHz 0.1 mHz - 10 MHz 0.1 mHz - 20 MHz
Output range open circuit 0 – 20 Vpp 0 - 40 Vpp 0 - 20 Vpp
Distortion for output 10-70% of voltage range 25-100% of voltage 10-70% of voltage range
voltages maximum
*2
range maximum
*2
maximum
*2
and frequencies 1Hz - 500kHz 1Hz - 500kHz 1Hz - 500kHz
Total harm.distortion < 0.4%, 0.1% typical < 0.4%, 0.1% typical < 0.4%, 0.1% typical
Harmonics fc:1Hz – 500kHz <-48dBc <-42dBc <-48dBc
Harmonics fc:500kHz-5MHz <-40dBc <-34dBc <-40dBc
Harmonics fc:5MHz–10MHz <-30dBc <-36dBc
Harmonicsfc:10MHz-20MHz <-34dBc
Subharmonics fc < 5MHz <-60dBc <-60dBc <-60dBc
Subharmonics fc > 5MHz <-38dBc <-38dBc
Square, Positive / Negative Pulses
Frequency range 0.1 mHz – 5 MHz 0.1 mHz – 10 MHz 0.1 mHz – 20 MHz
Output range open circuit 0 - 20Vpp 0 - 40Vpp 0 - 20Vpp
Pos/Neg. pulse open circuit 0 – 10 Vpp 0 – 20 Vpp 0 – 10 Vpp
Rise-/Fall time (at 50 % symmetry)
*2
f
C
: 0.1 mHz - 500 kHz ≤ 30 ns
f
C
> 500 kHz ≤ 20 ns
Aberration
*2
< 2% (AC > 200 mVpp)
Asymmetry See Waveforms
Triangle
Frequency range 0.1 mHz - 500 kHz
Output range 0 – 20 Vpp 0 – 40 Vpp 0 - 20 Vpp
Linearity error < 0.2% (f
C
<20 kHz)
Asymmetry See Waveforms
Positive / negative sawtooth
Frequency range 0.1 mHz - 50 kHz
Output range 0 - 10 Vpp 0 - 20 Vpp 0 - 10 Vpp
Linearity error <0.2% (f
C
< 20kHz)
Sine pulse, triangle pulse, haversine
Frequency range 0.1 mHz - 50 kHz
Output range 0 - 10 Vpp
Arbitrary (Instruments with interface)
Frequency range 0.1 mHz - 20 kHz
Sample frequency max. 20.48 MS/s
Waveform memories 24 (non volatile)
Memory length 1024 (10 bits)
Vertical resolution 1023 (10 bits)
Programmable via interface with a PC or direct with a DSO
Full scale output range 0 - 40Vpp open circuit 0 - 20Vpp open circuit
