PV350 English Instruction Sheet
Page 4
Battery
Figure 2. Battery Replacement
1. Turn the module OFF and unplug it from the DMM.
2. Remove the screw from the back of the module, separate the case,
and replace the battery.
3. To reassemble, line up the holes in the case with the
METRIC/ENGLISH switch and zero knob. Then snap the two halves
together. Reinstall the screw.
Typical Applications
Refer to Figures 3 and 4 for typical applications.
