Attachment FLUXTRONIC Automatic Mode 51 / 84
Only 8 of the 9 pins can be led outwards. Usually, the external start/stop is not led
outwards. Is the connection to be led with a plug outwards another function has to
be abstained from and changed on the socket.
The pulse redirection, Err, OK are not connected with an integral
switching amplifier FSV 100.
Assignment of the 5-pin version
The shielding is lead through on „black“ at the cable.
Assignment of the 8-pin version
The shielding is lead through on „black“ at the cable.
Examples:
The display is switched off when the flow meter is delivered.
The display can be switched on again by pressing a key.
By pressing the Cancel key several times, the user can ensure that the unit has
changed over to "START: Filling volume is displayed".
brown (9)
grey (6)
green (4)
blue (1)
yellow (2)
