Fly Products Thrust - Fitting the Harness High Attack

ASSEMBLY MANUAL __ REL . 1.1
___________________________________________________________________________
© Copyright by FLY PRODUCTS s.r.l. Pag.
6
La selletta viene fissata al telaio su tre punti di ancoraggio:
in alto con due bulloni a farfalla, di lato con due distanziali, in basso con due cinghie regolabili.
1) Upper hooks harness with two
Butterfly bolts
Attach the harness to the chassis with the plate
and tighten the two bolts with the butterflies.
ATTENTION
Mount the plate as is indicated on the sticker of
your paramotor
Asymmetric distance bar for:
Rider Thrust.
Anticlockwise rotation of the propeller
Asymmetric distance bar for:
Rider Jet, Rider Race C,
Clockwise rotation of the propeller
3
FITTING THE HARNESS HIGH ATTACK
