开机画面：
此为开机后LCD所显示的画面，在此画面下可显示如下内容：公司LOGO，当前电池电压，系统模式(AFHDS),当前机种编
号，当前机种名称，当前机类型（飞机还是直升机）,以及四个通道微调现在位置。
参数说明：
LOGO：显示的是富斯公司的商标。
TRIM：四个比率通道的微调。
AFHDS:此发射机系统模式为AFHDS（AUTOMATIC FREQUENCYHOPPING DIGITAL SYSTEM).
MODE：MODE0-MODE9共10组MODE可选择，当前是MODE1。
MODE：当前MODE的名称。
BATTERY：当前电池的电压，当电池电压低于9V时此图标会闪烁报警。
MODE TYPE：当前MODE的类型，有两种类型可供选择，一个是直升机，一个是飞机。
LOGO
TRIM
AFHDS
MODE
MODE
NAME
TRIM
BATTERY
TRIM
MODE
TYPE
TRIM
FS-T6
This is the image of starting LCD power on, the contents are as below: the LOGO of
company, the current voltage of battery, the mode of system (AFHDS), the current
No. of mode, the mode name, mode type (helicopters or aero) and initial position
of four trims.
Parameter instruction
LOGO: To show the LOGO of company
TRIM: The trim of four ratio fine channels
AFHDS is the mode system, which is abbreviation of Automatic frequency hopping
digital system.
MODE: There are totally 10 piece modes to be selected, the initial mode No. is MODE1.
MODE: The current name of MODE.
BATTERY: The current voltage of battery. When the voltage is less than 9V, it will
blink.
MODE TYPE: It shows the current MODE TYPE, there are two mode types to be chosen
one is helicopter and another is aero.
T-6.12
10
Start-up screen
