No.
Name
Parts
QTY
(a) M10*45 Screw 4
(b) M10*70 Screw 1
(c) M8*110 Screw 2
(e) M8*60 Screw 1
(f) M6*30 Screw 2
(g) M6*40 Screw 2
(h) M8 Pin 2
