ENGLISH - 4
Removing and Fitting the Blade and Fan
T1 - Blade bolt
T2 - Blade
T3 - Spacer
T4 - Fan
T5 - Pulley
• Always handle the blade with care - sharp
edges could cause injury.
• USE GLOVES.
Removing the Blade and Fan
1. To remove the blade bolt, hold the fan firmly
and, with a 13.0mm ring spanner, loosen
the blade bolt by turning it anti-clockwise (T).
2. Remove the blade bolt, blade, spacer and
fan from the pulley.(T)
3. Inspect for damage and clean as necessary.
• Renew your metal blade after 50 hours
mowing or 2 years whichever is the
sooner - regardless of condition.
• If the blade is cracked or damaged
replace it with a new one.
Fitting the Blade and Fan
1. Ensure the fan is located correctly.(T)
2. Fit the spacer to the fan. (T)
3. Fit the blade to the spacer. (T)
4. Re-assemble blade bolt through blade,
spacer and fan.
5. Hold the fan firmly and tighten blade bolt
firmly with a 13.0mm ring spanner. Do not
over tighten.
Caring for your Lawnmower
Cleaning (U)
• USE GLOVES
• IMPORTANT
It is very important that you keep your
lawnmower clean. Grass clippings left in
any of the air intakes or under the deck
could become a potential fire hazard.
1. Remove grass from under the deck with a
piece of wood or similar.
2. Remove the blade, see Figure T, to gain
access to the fan and clean with a soft
brush.
3. Remove grass clippings from:
• all air intakes
• wheels and height adjustment
levers
• grassbox
• grassbox lid and both sides of
grassbox full indicator
4. Clean around the switch actuator on the
grassbox (V1).
5. Wipe over the surface of your lawnmower
with a dry cloth.
• IMPORTANT
Never use water for cleaning your
lawnmower. Do not clean with chemicals,
including petrol, or solvents - some can
destroy critical plastic parts.
At the End of the Mowing Season
1. Replace blade, bolts, nuts or screws, if
necessary.
2. Clean your lawnmower thoroughly.
3. Ask your local Service Centre to clean the
air filter thoroughly and carry out any service
or repairs required.
4. Make sure that the electric cable is coiled
properly.
Storing the lawnmower (W)
The handles can be folded to take up the
minimum of space.
• Loosen the handle knobs
• Fold the upper handle over the lawnmower.
• Ensure the switchbox cable is not trapped.
• Store in a dry place where your
lawnmower is protected from damage.
Environmental Information
Electrolux Outdoor Products are manufactured
under an Environmental Management System
(ISO 14001) using, where practical, components
manufactured in the most environmentally
responsible manner, according to company
procedures, and with the potential for recycling
at the end of the products’ life.
• Packaging is recyclable and plastic
components have been labelled (where
practical) for categorised recycling.
• Awareness of the environment must be
considered when disposing of ‘end-of-life’
product.
• If necessary, contact your local authority for
disposal information.
