EN Electric Lawnmower
1. SAFETY ...............................................4
2. ASSEMBLY ............................................5
3. OPERATION ............................................5
4. MAINTENANCE .........................................6
5. STORAGE .............................................6
6. TROUBLESHOOTING ....................................7
7. TECHNICAL DATA .......................................7
8. ACCESSORIES .........................................7
9. SERVICE / WARRANTY .................................... 7
Original instructions.
This product may be used under supervision, or if
instruction regarding the safe use of the product
has been provided and the resulting dangers have been
understood, by children aged 8 and above, as well as by
persons with physical, sensory or mental disabilities or
a lack of experience and knowledge. Children must not be
allowed to play with the product. Cleaning and user mainte-
nance must not be performed by children without super-
vision. The use of this product by young people under the
age of 16 is not recommended.
Intended use:
The FLYMO Electric Lawnmower is intended to cut lawn in private
domestic gardens and allotments.
The product is not intended for long term use.
DANGER! Risk of injury!
v Do not use the product to cut bushes, hedges, shrubs, to cut
of climbers or grass on roofs or balcony boxes, to chop up
branches, twigs and to level irregularities in the soil. Do not
use the product on a slope steeper than 20° maximum.
1. SAFETY
Important! Read the operator’s manual carefully before use and keep
for future reference.
Symbols on the product:
Read operator’s manual.
Keep other persons away.
Beware of sharp blades. Blades continue to rotate after
the engine is switched off. Disconnect the mains cable
before you do maintenance or if the cable becomes
damaged or cut.
Keep the mains cable away from the cutting blades.
General safety warnings
Electrical safety
DANGER! Electric shock!
Risk of injury due to electric shock.
v
The product must be supplied through a residual current device (RCD)
having a rated residual operating current not exceeding 30 mA.
DANGER! Risk of physical injury!
Cut injury when the blade turns or the product starts accidentally.
v Disconnect the product from the mains before you do maintenance
oryou replace parts. Thereby the disconnected socket must be in the
visual range.
Cables
If extension cables are used, these must comply with the minimum cross-
sections in the table below:
Voltage Cable length Cross section
220 – 240 V / 50 Hz Up to 40 m 1.0 mm
2
220 – 240 V / 50 Hz Up to 60 m 1.5 mm
2
220 – 240 V / 50 Hz Up to 100 m 2.5 mm
2
Minimum rating: 1.0 mm
2
size cable, 10 amps 250 volts AC.
Your product is supplied with cable wired directly into the product.
1. If the supply cord is damaged, it must be replaced by your local
Husqvarna UK Ltd. Approved Service Centre or similarly qualified
persons in order to avoid a hazard.
2. Flymo Extension Cables are available from your local Husqvarna UK Ltd.
Approved Service Centre.
3. Do not wire an extension cable directly to your product yourself. Please
contact your local Husqvarna UK Ltd. Approved Service Centre for further
information on the connectors and kits available.
4. Only use extension cables specifically designed for outdoor use and
which conform to one of the following specifications:
Ordinary rubber (60245 IEC 53), Ordinary PVC (60227 IEC 53) or
Ordinary PCP (60245 IEC 57).
Connectors – Important
• Flymo connectors are suitable for use with 2 core cable only. Under no cir-
cumstances should these connectors be used for earthed products.
• All Flymo connectors and cables are of splashproof construction. They are not
waterproof and must not be left outside permanently nor should they be sub-
merged or immersed in water. Do not let cable lay or trail through pools of
water or splashed with water from hose pipes.
Mains plug replacement – Important
• If the plug supplied is cut off it should be destroyed. There is an electric shock
hazard if a cut off plug is inserted into a 13 amp socket.
1. No earth required. Flymo products are double insulated to EN60335 and
under no circumstances should an earth be connected to any part of the
product.
2. Ensure the mains voltage suits your product.
3. Important! The wires in the mains lead are coloured in accordance with the
following code: BLUE – NEUTRAL; BROWN – LIVE. The wire which is colour-
ed BLUE must be connected to the Terminal which is marked with the letter
‘N’ or coloured BLACK. The wire which is coloured BROWN must be con-
nected to the Terminal which is marked with the letter ‘L’ or coloured RED.
4. It is important that the outer sheath is clamped correctly into the 3-pin plug.
5. If in doubt consult your local Service Repairer or qualified electrician before the
machine is used.
6. A 13 Amp fuse must be fitted to the mains plug.
7. The normal plug fuse and household fuse only protect the electrical equip-
ment and are not a safeguard against electrocution.
Training
1. Read the instructions carefully. Be familiar with the controls and the correct
use of the machine.
2. Never allow children or people unfamiliar with these instructions to use the
machine. Local regulations can restrict the age of the operator.
3. Never operate the machine while people, especially children, or pets are
nearby.
4. Keep in mind that the operator or user is responsible for accidents or hazards
occurring to other people or their property.
Preparation
1. While operating the machine always wear substantial footwear and long trou-
sers. Do not operate the machine when barefoot or wearing open sandals.
Avoid wearing clothing that is loose fitting or that hanging cords or ties.
2. Thoroughly inspect the area where the machine is to be used and remove all
objects which can be thrown by the machine.
3. Before using, always visually inspect to see that the blade, blade bolt and the
blade assembly are not worn or damaged. Replace worn or damaged com-
ponents in set to preserve balance. Replace damaged or unreadable labels.
4. Before use check the supply and extension cord for signs of damage or
aging. If the cord becomes damaged during use, disconnect the cord from
the supply immediately. DO NOT TOUCH THE CORD BEFORE DISCON-
NECTING THE SUPPLY. Do not use the machine if the cord is damaged or
worn.
Operation
1. Operate the machine only in daylight or in good artificial light.
2. Avoid operating the machine in wet grass.
3. Always be sure of your footing on slopes.
4. Walk, never run.
5. Mow across the face of slopes, never up and down.
6. Exercise extreme caution when changing direction on slopes.
7. Do not mow excessively steep slopes.
8. Use extreme caution when reversing or pulling the machine towards you.
9. Stop the blade(s) if the machine has to be tilted for transportation when
crossing surfaces other than grass, and when transporting the machine to
and from area to be used.
