CABLES - IMPORTANT
If you want to use an extension cable when operating your
product, only the followint cable dimensions should be used:
- 1.0 mm
2
: max length 40 m
- 1.5 mm
2
: max length 60 m
- 2.0 mm
2
: max length 100 m
Minimum rating :
1.00mm
2
size cable, 10 amps 250 volts AC.
THE PRODUCT IS SUPPLIED WITH CABLE WIRED
DIRECTLY INTO THE PRODUCT
1. Flymo Mains Cables and Extension Cables are avail-
able from your local Approved Service Centre.
2. Do not wire an extension cable directly to your product
yourself. Please contact your local Approved Service Centre
for further information on the connectors and kits available.
3.
Only use extension cables specifically designed for
outdoor use and which conform to one of the following
specifications: Ordinary rubber (60245 IEC 53), Ordi-
nary PVC (60227 IEC 53) or Ordinary PCP (60245
IEC 57)
CONNECTORS - IMPORTANT
• Flymo connectors are suitable for use with 2 core
cable only. Under no circumstances should these
connectors be used for earthed products.
• All Flymo connectors and cables are of splashproof
construction. They are not waterproof and must not
be left outside permanently nor should they be sub-
merged or immersed in water. Do not let cable lay or
trail through pools of water or splashed with water
from hose pipes.
MAINS PLUG REPLACEMENT
• If the plug supplied is cut off it should be destroyed.
There is an electric shock hazard if a cut off plug is in-
serted into a 13 amp socket.
1. No earth required. Our products are double insulated to
EN60335 and under no circumstances should an earth
be connected to any part of the product.
2. Ensure the mains voltage suits your product
3. IMPORTANT!
The wires in the mains lead are coloured in accor-
dance with the following code:
BLUE - NEUTRAL BROWN - LIVE
The wire which is coloured BLUE must be connected to
the Terminal which is marked with the letter 'N' or
coloured BLACK. The wire which is coloured BROWN
must be connected to the Terminal which is marked with
the letter 'L' or coloured RED.
4. It is important that the outer sheath is clamped cor-
rectly into the 3-pin plug.
5. If in doubt consult your local Service Repairer or quali-
fied electrician before the machine is used.
6. A 13 Amp fuse must be fitted to the Mains Plug.
7. The normal plug fuse and household fuse only protect
the electrical equipment and are not a safeguard
against electrocution.
aged cable. Replace it with a new one.
5. Your cable must be uncoiled, coiled cables can over-
heat and reduce the efficiency of your product.
6.
Keep cables away from the cutting element. The cutting
element can cause damage to cables and lead to con-
tact with live parts. A
lways work away from the power
point using up and down, never in circles.
7. Do not pull cable around sharp objects.
8. Always switch off at the mains before disconnecting
any plug, cable connector or extension cable.
9. Switch off, remove plug from mains and examine electric
supply cable for damage or ageing before
winding cable
for storage. Do not repair a damaged cable, replace it
with a new one. Use only Flymo replacement cable.
10. Always wind cable carefully, avoiding kinking.
11. Never carry the product by the cable.
12. Never pull on the cable to disconnect any of the plugs.
13. Use only on AC mains supply voltage shown on the
product rating label.
14. Our products are double insulated to EN60335.
Under no circumstance should an earth be con-
nected to any part of the product.
Preparation
1. While using your product always wear substantial
footwear and long trousers.
2. Make sure the lawn is clear of sticks, stones, bones, wire
and debris; they could be thrown by the plastic cutters.
3. Before using the machine and after any impact, check
for signs of wear or damage and repair as necessary.
4. Replace worn or damaged plastic cutters together with
their fixings in sets to preserve balance.
Use
1. Use the product only in daylight or good artificial light.
2.
Do not operate whilst people especially children or
pets are in the area.
3.
Avoid operating your product in wet grass, where feasible.
4. Take care in wet grass, you may lose your footing.
5. On slopes, be extra careful of your footing and wear
non-slip footwear.
6. Use across the face of slopes, never up and down.
7. Exercise extreme caution when changing direction
on slopes.
Walk never run.
8. Using on banks and slopes can be dangerous. Do
not use on banks
or steep slopes.
9.
Use extreme caution when reversing or pulling the
product towards you.
10. Switch off before pushing the product over surfaces
other than grass.
11. Never operate the product with damaged guards or
without guards in place.
12.
Switch on the motor according to instructions and
with feet well away from the cutting element. Do not
put hands or feet near or under rotating parts.
13. Warning, Cutting elements continue to rotate after
the motor is switched off.
14. Do not tilt the product when the motor is running, ex-
cept when starting and stopping. In this case, do not
tilt more than absolutely necessary and lift only the
part which is away from the operator. Always ensure
that the hand is in the operating position before re-
turning the appliance to the ground.
15. Never pick up or carry a product when it is operating
or still connected to the mains supply.
16. Remove the plug from the mains :
- before leaving the product unattended for any period;
- before clearing a blockage;
- before checking, cleaning or working on the appliance;
- if you hit an object. Do not use your product until you
are sure that the entire product is in a safe operating
condition;
- if the product starts to vibrate abnormally. Check imme-
diately. Excessive vibration can cause injury.
Maintenance and storage
1. Caution - Do not touch rotating plastic cutters
2. Keep all nuts, bolts and screws tight to be sure the
product is in safe working condition.
3. Check the grassbox frequently for wear or deteriora-
tion.
4. Replace worn or damaged parts for safety.
5. Only use the replacement spare parts and acces-
sories specified for your product.
6. Be careful during adjustment of the product to pre-
vent entrapment of the fingers between moving plas-
tic cutters and fixed parts of the machine.
7.
Store in a cool dry place and out of reach of children.
Do not store outdoors.
8.
Allow the product to cool for at least 30 minutes be-
fore storing.
If your product is hard wired i.e. non detachable mains
electric cable, a conversion kit and extension cable is
available from all Approved Service Centres which can
be found in your local yellow pages.
