F
G
1
J
K
L
x 5-6
M1
M2
Attaching the Shoulder Harness
1. Attach the Shoulder Harness to the product as
illustrated in Fig H
2. Adjust the Shoulder Harness as required to ensure
it is in the most comfortable position and the col-
lection tube is positioned slightly above the debris.
(J).
Securing the Access Screw
1, Remove the label from over the Access Screw (K).
2. Turn the Access Screw 5-6 times clockwise (L)
until tight (do not overtighten)
• Important:- Your product will not operate if the
Access Screw is not tightened.
Cable Restraint
1. Form loop in mains cable and push the loop
through the slot (M1).
2. To secure, position loop over the hook and pull
the cable back through the slot (M2).
H
Assembly Instructions (continued)
