6-1-2 Connectors & Functions
Connector Function
CN3 USB CONN
CN4 Speaker and MIC CONN
CN5 HDD Power
CONN
CN6 USB CONN
CN12 PS2 Ke
y
board CONN
CN18 Power LED CONN
CN22 Power Button CONN
CN25 Batter
y
CONN
PWR3 DC-JACK
CN25 Batter
y
CONN
DDR3_A1 DDR3 SO-DIMM1
RJ11_3 Cash Drawer Port
RJ45_3 LAN Port
RJ45_4 COM1~4 Port
SATA1 7+15 Pin SATA CONN
PWR BUT Power Button
VGA3 VGA Port
USB3 USB Port
USB4 USB Port
JP3 Cash Drawer power selection
JP8 CRT Power Settin
g
JP9 COM Power Settin
g
