6-2-2 Connectors & Functions
Connector Function
CN4 Power LED CONN
CN6 Speaker & MIC CONN
CN8 HDD Power CONN
CN10 Printer Port CONN
CN11/12 USB CONN
CN14 PS2 Keyboard CONN
CN17 Power Button CONN
CN18 TO Front I/O Board
PWR1/2 DC-JACK
RJ11_1 Cash Drawer Port
RJ45_1 LAN Port
RJ45_2 COM1~4 Port
DDR3_A1 DDR3 SO-DIMM
SATA1 SATA CONN
SATA2 7+15 Pin SATA CONN
USB1 USB Port
USB2 USB Port
VGA1 VGA Port
SW1 Power Button
JP5 COM2 Power Setting
JP6 COM3/COM4 Power Setting
JP9 CASH DRAWER Power Setting
