FMI 36" - Firebox Installation with Custom Mantels; Cabinet Mantel Installation Steps

www.fmiproducts.com
124384-01a 13
Figure 12 - Inserting Firebox Into Cabinet
Mantel (Mantel May Vary From Illustration)
Figure 11 - Installing Cabinet Mantel
(Mantel May Vary From Illustration)
Cabinet
Mantel
Gas
Piping
Gas Line
Access Hole
(Either Side
of Firebox)
INSTALLATION
Continued
WARNING: Use only non-
combustible mortar or adhe-
sives when overlapping the front
facing with noncombustible
facing material.
INSTALLING FIREBOX USING
OPTIONAL CUSTOM BUILT
MANTELS
WARNING: A qualied ser-
vice person must install rebox.
Follow all local codes.
This rebox may be installed using a cabinet
mantel against a wall in your home. The
rebox and cabinet mantel can be installed
directly on the oor. Mantels may be avail-
able from your retailer or custom built for
your home.
1. Assemble cabinet mantel as instructed.
2. Install gas piping to rebox location. See
Installing Gas Line, page 14. You may have
to cut an access hole in the oor or wall to
run gas line to rebox. Make sure to locate
access hole so cabinet mantel will cover it
when installed (see Figure 11).
3. Place rebox on oor in desired location.
Make sure mantel will be ush against
wall when installed.
4. Carefully slide cabinet mantel over rebox.
Be careful not to scratch rebox, cabinet
mantel, ooring, etc., when installing (see
Figure 12).
5. Install and properly test gas log heater.
Follow installation instructions included
with the vent-free gas log heater that is
being installed.
